Yamaha 30A - Inspecting and Replacing Anode(S)

4-26
E
603023
902054
To clean the fuel tank
1) Empty the fuel tank into an approved
gasoline (petrol) container.
2) Pour a small amount of suitable sol-
vent in the tank. Reinstall the cap and
shake the tank. Drain the solvent
completely.
To clean the fuel filter
1) Remove the screws holding the fuel
hose joint assembly . Pull the assem-
bly out of the tank.
2) Clean the filter (located on the end of
the suction pipe) in a suitable clean-
ing solvent. Allow the filter to dry.
3) Replace the gasket with a new one.
Reinstall the fuel hose joint assembly
and tighten the screws firmly.
EMU00831
INSPECTING AND REPLACING
ANODE(S)
Yamaha outboard motor is protected
from corrosion by a sacrificial anode(s).
Check the anode(s) periodically. Remove
the scales from surfaces of the anode(s).
For the inspection and replacement of the
anode(s), consult a Yamaha dealer.
cC
Do not paint the anode(s), for this would
render it ineffective
6L2-9-1H 4 4/20/01 1:49 PM Page 27
