Yamaha 30A - Oil Level Warning; Oil Filter Clogging Warning

2-15
E
213023
q
303014
30
EMU00172
OIL LEVEL WARNING / OIL FILTER
CLOGGING WARNING
This engine has an oil level warning sys-
tem. If oil level falls below lower limit, the
warning device will activate.
(
2); Included (—); N/A
If the warning system has been activated,
stop the engine and check for the cause.
NOTE:
The warning for oil filter clogging is simi-
lar to the warnings for low oil level and
overheating. For easy troubleshooting, it
is advisable to check for engine overheat-
ing first, then oil level and finally oil filter
clogging.
1 Oil filter
Warning device
activation
The engine speed
will automatically
decrease to about
2,000 r/min.
The oil level warning
indicator will come on.
The buzzer will sound.
Tiller Remote
control control
model model
2 2
2 2
— 2
