E
3-30
3) Pull up the shallow water lever.
4) Slightly tilt up the engine. The tilt-
support bar will lock automatically,
supporting the engine in a partially
raised position.
NOTE:
If the engine is tilted up completely, the
tilt-lock lever automatically locks. The
shallow water lever is no longer effective.
5) When lowering the engine, set the tilt-
lock lever and shallow water lever to
the lock position. Slightly tilt up the
engine until the tilt-support bar auto-
matically returns to the free position.
Then, slowly lower the engine to the
normal position.
412022
25-3/30
25-3/30
25
25
EMG80511*
PROCEDURE
25-3/30
1) Push the shallow water lever down to
the release position.
2) For setting the outboard motor at the
partially tilted position, slightly tilt up
the engine until the plate turns com-
pletely
3) To return the engine to the normal
position, put the engine in Neutral,
then slightly tilt up the engine. Set the
tilt-lock lever and shallow water lever
to the lock position and slowly tilt the
engine down.
