Yamaha 40 - Main Components Overview

101133*
w
e
r
q
t
y
u
!5
!4
!3
!2
!1
!0
o
i
902056
2-1
GB
EMU01206
MAIN COMPONENTS
1 Recoil starter handle
2 Multifunction tiller handle
3 Choke knob
4 Warning indicator lamp
5 Tilt lock lever
6 Transom clamp handle
7 Trim angle adjusting rod
8 Cooling water inlet
9 Propeller
0 Trim tab (Anode)
q Anti-cavitation plate
w Anode
e Tilt support lever
r Clamp bracket
t Top cowling
y Fuel tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
40VMHO/40YMHO/50HMHO
!6
63B-9-78-A0-2 2/17/03 4:26 PM Page 4
