MAIN COMPONENTS
1 Oil filler access cap
2 Warning indicator lamp
3 Clamp bracket
4 Battery lead
5 Anode
6 Cooling water inlet
7 Propeller
8 Trim tab (Anode)
9 Anti-cavitation plate
0 Anode
q Trim angle adjusting rod
w Tilt support lever
e Top cowling
* r Remote control box
* t Digital tachometer
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
