Yamaha 40C - Digital Tachometer

E
2-9
EMU01614
DIGITAL TACHOMETER
This gauge contains the tachometer, trim
meter, hour meter, oil level indicator, and
the overheat warning indicator.
1 Tachometer
2 Trim meter
3 Hour meter
4 Oil level indicator
5 Overheat warning indicator
6 Set button
7 Mode button
NOTE:
All segments of the display will light
momentarily after the main switch is
turned on and will return to normal there-
after.
q
t
w
u
y
e
r
001078
001082
001049
EMU00136
Tachometer
This meter shows the engine speed.
