Yamaha 40C - Tilt Support Lever; Top Cowling Lock Lever

E
2-13
301013*
q
EMD60010
TILT SUPPORT LEVER
Power trim & tilt/Hydro tilt model
To keep the outboard motor in the tilted-
up position, lock the tilt support lever to
the clamp bracket.
403011
EMD62011
TOP COWLING LOCK LEVER
To remove the engine top cowling, turn
the lock lever. Then lift off the cowling.
When replacing the cowling, check to be
sure it fits properly in the rubber seal.
Then lock the cowling again by moving
the lever upward.
1 Top cowling lock lever
