E
3-22
EMG63210
PROCEDURE FOR TILTING UP
Power trim and tilt model
1) Remove the fuel-line connection from
the motor.
304036
UP
DN
701034
UP
DN
302013*
DN
UP
2) Push the power trim and tilt switch
“UP” until the outboard has tilted up
completely.
w
Leaking fuel is a fire hazard. Disconnect
the fuel line if the engine will be tilted for
more than a few minutes. Otherwise, fuel
may leak. (If the fuel connector is provid-
ed on the motor.)
