3-12
REMOTE CONTROL TYPES AND APPLICATIONS
DEC ENGINE SELECTION
This RC unit accepts all DEC engines.
The initial setting is completed to match new DEC engines.
If this RC unit is used for previous DEC engines such as F250B and F300 (V8) for 2011 model, fol-
low the procedure below.
1. Remove the black cap.
2. Disconnect the white coupler, and connect it to the black coupler.
3. Attach the black cap to the white coupler for waterproofing.
* If the re-setting is wrong, the engine will not start.
* The RC unit with variation code [A] is not required for setting to select the engine.
BLK
WHT
BLK
CapCap
Br Br
For previous
DEC engine
For previous
DEC engine
For new DEC engine
(initial setting)
For new DEC engine
(initial setting)
Example: twin engine application
WHT
WIRE-HARNESS
P
P S
S
To Next Page
