3-13
REMOTE CONTROL TYPES AND APPLICATIONS
6X6 BINNACLE MOUNT R
EMOTE CONTROL DIMENSIONS
The side view is the same among al
l remote control unit va
riation.
Single engine application
To be continued.
F
N
R
Throttle range
Throttle range
5 deg.
Shift
range
Shift
range
22.5
deg.
22.5
deg.
Max.
67 deg.
Max.
90 deg.
225 (8.86)
35 (1.38)
170 (6.69)
128 (5.04)
182 (7.17)
mm (in.)
106 (4.17)
Template (single lever)
132 (5.20)
145 (5.71)
59 (2.32)
62 (2.44)
5.5 (0.22)
Cut out shaded area
Cut out shaded area
100
102
