REMOTE SWITCH TYPES AND APPLICATIONS
SINGLE IG SWITCH W/ PANEL
SINGLE IG SWITCH W/O PANEL
Ref. No. Part No. Description
1 704-8257C-01 With choke switch
130 (5.12)
Cut out shaded area
51 (2.0)
25.5 (1.0)
68 (2.68)
113 (4.49)
24 (0.94)24 (0.94)
52.4 (2.06)
5.5 (0.22)
140 (5.51)
86 (3.39)
Or
YBr
P
W
B
3
mm (in.)
20 (0.79)
16 (0.63)
1
mm (in.)
Max. 4 (0.16)
B
Y
G
R
140 (5.51)
355 (13.98)
3.5 Nm,
0.35 kgf㨯m,
2.6 ft㨯lb
B(W)
W(B)
P
R
B
G
Y
L
Br
W
Max. 4 (0.16) 101 (3.98)
