3-20
REMOTE SWITCH TYPES AND APPLICATIONS
TWIN IG SWITCH
To be continued.
Ref. No. Part No. Description
1
6K1-82570-12 w/ choke SW
61B-82570-05 w/o choke SW
2 6Y8-82570-03 For Digital Network System (6Y8), Main station helm
3 6X6-82570-40 For Digital Network System (6Y9), Main station helm
4 6X6-82570-10 For Digital Network System (6Y8), 2nd helm
5
6X6-82570-60 For Digital Network System (6Y9), main station helm, w/o buzzer, Requires [No.3]
6X6-82570-E0 For Digital Network System (6Y9), 2nd station helm, w/ buzzer
128 (5.04)
25.9 (1.02)
54 (2.13)
93 (3.66)
24.25 (0.95)
5.6 (0.22)
66 (2.60)
Cut out shaded areaCut out shaded areaCut out shaded area
113 (4.45)
25 (0.98)
138 (5.43)
154 (6.06)
50 (1.97)
66 (2.60)
54
(2.13)
5.5 (0.22)
Cut out shaded area
*110 (4.33)
3.3 (0.13)
*For reference
338 (13.3)
Cut out shaded area
110 (4.33)
B
Y
G
R
145 (5.71) 97 (3.82)
110 (4.33)
140 (5.51)
340 (13.39)
P
R
B
G
Y
L
Br
W
1
2
mm (in.)
mm (in.)
To Next Page
