3-47
DIGITAL ELECTRONIC REMOTE CONTROL WIRE HARNESS
DUAL STATION WIRE-HARNESS (2-12P)
Used to connect between main RC and 2nd RC
DUAL STATION WIRE-HARNESS (3-12P)
Used to connect between main RC and 2nd RC (Quad engine special)
CONVERSION HARNESS L
Used to connect between new DEC unit and previous main switch.
Part No. Length (L) Remarks
6X6-8258A-B1 5 m (16 ft)
For DEC unit6X6-8258A-D1 8 m (26 ft)
6X6-8258A-F1 12m (38 ft)
Part No. Length (L) Remarks
6X6-8258A-R0 5 m (16 ft)
For new DEC unit6X6-8258A-S0 8 m (26 ft)
6X6-8258A-T0 12 m (38 ft)
Part No. Length (L) Remarks
6X6-8258A-L0 150 mm (6 in) For new DEC unit
R
Or
R
Y
Or
R R R
R
Y
2nd RC Main RC
(L)
W/L
X
R/Y
X
X X Or X
RRRR
W/B
X
R/Y
X
X X Or X
RRRR
Or
W/L
R/Y
Or
W/B
R/Y
P
P
S
S
(L)
YB
XX
WXPBr
XXRX
BY
Br P W
X
R
X
To DEC To SW panel
(L)
To Next Page
