6X4 MULTI-FUNCTION TILLER HANDLE
TILLER HANDLE KIT CONTENTS
F75A, F90A
KIT P/N:6X4-42102-11
Part name Part No. Q’ty Remarks
Fuel pipe clamp 2 63D-24367-00 1
Cable clamp 1 63D-48538-00 2
Throttle cable 67G-26301-10 1 895 mm (35 in.)
Pipe 1 67G-42541-00 1
Pipe 1 67G-42541-10 1
Nut 67G-42546-00 2
Shift cable 67G-48321-20 1 965 mm (40 in.)
Grommet 2 68V-42725-10 1
Corrugated tube 6G5-83557-00 1 85 mm (3.3 in.)
Corrugated tube 6K3-83557-00 1 65 mm (2.6 in.)
Stay 6X4-24364-00 1
Ext. bracket (Short)
6X4-42121-00-8D
1 45 mm (1.8 in.)
Protector 6X4-42735-00 1
Troll RPM switch ASSY 6X4-81860-00 1
10-pin main harness 6X4-82586-20 1 1250 mm (49 in.)
Stud bolt 90116-10031 2 M10-70 mm
Bolt 90119-08M74 2
locknut 90185-08057 2
locknut 90185-10027 2 M10
Washer 90201-08M01 2
Corrugated tube 90447-22007 1 230 mm (9.1 in.)
Clamp 90464-09M42 1
Clamp 90465-13M24 5
Clamp 90465-13M30 1
Clip 90468-10005 2
Bolt 97595-06516 2
Bolt 97595-08525 2
Friction plate 3 63D-42527-00 1
Friction piece 63D-42528-00 2
Steering lock knob 67G-42561-00 1
Steering lock shaft 67G-42562-00 1
Cover 68243-31801 1
Friction plate 2 6X4-42526-00 1
locknut 90185-10M14 1
Washer 90201-10M76 1
