4-7
6X4 MULTI-FUNCTION TILLER HANDLE
TILLER HANDLE KIT CONTENTS
F50B, T50B, F60B, T60B, F70A
KIT P/N:6X4-42102-23
Part name Part No. Q’ty Remarks
Cable clamp 1 63D-48538-00 2
Shift cable 67C-48321-11 1 707 mm (28 in.)
Throttle cable 69W-26301-00 1 610 mm (24 in.)
Troll RPM switch ASSY 6X4-81860-00 1
10-pin main harness 6X4-82586-10 1 1250 mm (49 in.)
Bolt 90109-06M88 2
locknut 90185-10027 2 M10
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Washer 92990-06100 2
Friction piece 65W-42528-00 2
Friction plate 1 67C-42525-00 1
Steering lock knob 67C-42561-00 1
Steering lock shaft 67C-42562-00 1
Tilt lever cover 689-43633-00 1
Friction plate 3 6C5-42527-00 1
locknut 90185-10M14 1
Washer 90201-106M5 1
Plate washer 90202-10M56 1
Washer 90209-10M26 1
Collar 90387-05053 1
Collar 90387-05054 1
Nut 95380-05600 1
Bolt 97595-05520 1
