3-7
REMOTE CONTROL TYPES AND APPLICATIONS
REMOTE CONTROL SPACER
Designed to raise the control box 22 mm (0.9 in.) to make more clearance between the lever and
the dash board when the lever is in the WOT position.
6X3 CONCEALED REMOTE CONTROL [Mechanical RC]
Designed for the electric start models. Best fitted to runabout type boats. The emergency shut-off
switch is incorporated into the control box.
The mounting position can be selected from horizontal or inclined 30-degree up or down position
depending on the boat design.
* The ignition switch panel without engine shut-off cord and 10-pin main harness are required to connect to
the engine.
* Throttle opening direction can be reversed.
* For further information, see the instruction in the package.
Ref. No. Part No. Descriptions
1 704-48293-20 Single
2 704-48293-30 Twin
Part No.
Throttle
PTT
Mount
Remarks
Push
Pull R L
6X3-48206-01 1 1 1
With emergency shut-off cord
(2-pin coupler)
To Next Page
