Yamaha 60A - Tilt Support Lever; Top Cowling Lock Levers; Flushing Device

E
2-12
403011*
q
301041*
000945
q
EMD60010
TILT SUPPORT LEVER
To keep the outboard motor in the tilted-
up position, lock the tilt support lever to
the clamp bracket.
q
301042*
EMD63111
TOP COWLING LOCK LEVERS
To remove the engine top cowling, turn
the front lock lever and rear lock lever(s).
Then lift off the cowling. When replacing
the cowling, check to be sure it fits prop-
erly in the rubber seal. Then lock the
cowling again by returning the levers to
the locked position.
1 Top cowling lock lever
EMU01146
FLUSHING DEVICE
This device 1 is used to clean the cooling
water passages of the motor using a gar-
den hose and tap water.
NOTE:
Refer to “Cleaning Cooling-water
Passages” in Chapter 4 for instructions on
usage.
6H3-9-1L 2 4/26/01 5:24 PM Page 2-12
