E
3-20
302021*
DN
UP
403011*
411014
EMU00295
PROCEDURE FOR TILTING UP
Power tilt / Power trim/tilt model
1) Remove the fuel-line connection from
the motor. (If the connector is provid-
ed on the motor.)
2) Push the power tilt / power trim/tilt
switch “UP” until the outboard has
tilted up completely.
3) Turn the tilt-support lever toward you
and support the engine.
w
After tilting the engine, be sure to sup-
port it with the tilt-support lever.
Otherwise, the engine could fall back
down suddenly if oil in the power tilt /
power trim/tilt unit should lose pressure.
Power trim/tilt model
4) Once the engine is supported with the
tilt-support lever, push the power
trim/tilt switch DOWN to retract the
trim rods.
6H3-9-1L 3 4/26/01 5:27 PM Page 3-20
