5-8
GB
Procedure
1) Remove the top cowling.
2) Remove the flywheel cover by remov-
ing the bolts.
3) Prepare the engine for starting. See
“STARTING ENGINE” for procedures.
Be sure the engine is in Neutral and
that the lanyard is attached to the
engine stop switch. The main switch
must be on.
305034
NOTE:
8 In this case, choke switch will not oper-
ate. Pull out the choke knob when
engine is cold.
8 Without setting the main switch to
“ON”, it is impossible to start the
engine.
4) To start the engine with the emer-
gency starter rope, insert the knotted
end of the rope into the notch in the
flywheel rotor and wind the rope sev-
eral turns clockwise. Then, give a
strong pull straight out to crank the
engine. Repeat if necessary.
w
Do not install the top cowling when
engine is running.
55/75/85
