MAIN COMPONENTS
1 Top cowling
2 Tilt support lever
3 Anti cavitation plate
4 Trim tab (Anode)
5 Propeller
6 Cooling water inlet
7 Battery cable
8 Anode
9 Clamp bracket
0 Cowling lock lever
q Remote control box
w Trim meter
e Tachometer
r Remote oil tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
