Appendix
General specifications
0 dBu = 0.775 Vrms, Output impedance of signal generator (Rs) = 150 Ω
All level controls are nominal if not specified.
Frequency response
Microphone preamp
input → PHONES OUT
via USB IN/OUT
+0.5 dB/-1.5 dB (20 Hz to 20 kHz @ Fs = 192 kHz) with a nominal output
level reference @ 1 kHz, MIC GAIN: MID, STREAMING OUT: MIC
Total harmonic
distortion *1 (THD+N)
Microphone preamp
input to PHOENS OUT
0.1% @ -2.0 dBu (50 Hz to 20 kHz), MIC GAIN: MID
0.01% @ +0.0 dBu (1 kHz), MIC GAIN: MID
Hum and noise *2 (20
Hz to 20 kHz)
Residual output noise −103 dBu (PHONES knob: Min)
Crosstalk (1 kHz) *3 −80 dB
Input channels
Microphone: 1
AUX: 1, USB IN: 1, Smartphone IN: 1
Output channels
PHONES: 1
USB OUT: 1, Smartphone OUT: 1
Microphone function
GAIN HIGH, MID, LOW
DSP COMP/EQ *4, REVERB, MUTE
USB audio 2 IN / 2 OUT Sampling frequency: up to 192 kHz, Bit depth: 24-bit
Power requirements DC 5V, 900 mA
Power consumption Max. 4.5 W
Dimensions (W×H×D) 116 mm × 281 mm × 118 mm (4.6" x 11.1" x 4.6")
Net weight 1.2 kg (2.6 lb)
Included accessories
USB2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download
Information, Cubase AI Download Information
Operating temperature 0 to +40℃
*1 THD+N is measured with 22 kHz LPF.
*2 Noise is measured with A-weighting filter.
*3 Crosstalk is measured with 1 kHz band pass filter. PHONES OUT L / R.
*4 Setting by AG Controller.
The contents of this guide apply to the latest specifications as of the publishing date.
