5 Using a 3.5 mm four-conductor (TRRS) stereo mini cable, connect the [CH7/8 (P)
LINE IN/OUT] smartphone input/output jack to the headset jack on your Android
device.
Android device
4-conductor (TRRS),
3.5 mm stereo mini cable
NOTE
(
You will need a conversion adapter cable if your Android device does not have a jack for connecting stereo mini plugs.
(
For example, for Android devices that use a USB-C port to input/output audio, you’ll need a USB-C to 3.5 mm four-
conductor (TRRS) earphone jack conversion adapter cable.
(
Use a four-conductor (TRRS) stereo mini cable, not a two- or three-conductor (TS/TRS) cable.
2-conductor (TS) 3-conductor (TRS) 4-conductor (TRRS)
No No Yes
One insulator band Two insulator bands Three insulator bands
Once connected, use your music playback or recording app to test whether the audio is being inputted and
outputted.
