Connecting to Android devices
This explains what to do to power this unit, up through connecting to an Android device.
What you need
(
3.5 mm 4-conductor stereo mini cable
NOTE
(
This product can’t input/output audio via the USB cable.
(
The audio signal sent to the Android device is monaural.
(
When using this product for streaming or otherwise using it for long periods of time, have a power supply on hand for powering
your Android device.
1 Make sure that the volume on this product and on the connected device is turned
all the way down.
2 Connect the included AC adapter to the [12V] DC jack on the rear panel, and slide
the [POWER SOURCE] selector switch to [12V] DC (left side).
Rear panel
AC adapter
(included)
3 Turn the [z] (standby/on) switch on.
4 After the LED light animation on the top panel of this unit finishes, check whether
the LED of the [z] (standby/on) switch on this product is lit.
32
Getting ready to use this product > Connecting to Android devices
