Appendix
General specifications
0 dBu = 0.775 Vrms, Output impedance of signal generator (Rs) = 150 Ω
All level controls are nominal if not specified. The nominal knob setting is at the three-o’clock position.
Frequency response
Input channels *4
→MONITOR OUT
+0.5 dB/−1.5 dB (20 Hz to 20 kHz) with a nominal output level reference @
1 kHz; GAIN knob: min
Total harmonic
distortion *1 (THD+N)
Input channels *4
→MONITOR OUT
0.03 % @ 0 dBu (20 Hz to 20 kHz); GAIN knob: min
0.008 % @ +4 dBu (1 kHz), GAIN knob: min
Hum and noise *2
(20 Hz to 20 kHz)
Equivalent input noise −128 dBu (mono input channel, Rs: 150 Ω; GAIN knob: max)
Residual output noise −93 dBu (MONITOR OUT, MONITOR knob: min)
Crosstalk (1 kHz) *3 *4 −80 dB
Input channels
Monaural (MIC/LINE): 2, including HEADSET MIC (plug-in power) input
(CH 1 MIC and HEADSET MIC cannot be used simultaneously),
Stereo (LINE): 3
Output channels
MONITOR OUT: 1, MIX OUT: 1, PHONES: 2 (PHONES and HEADSET
PHONES cannot be used simultaneously.), AUX OUT: 1
Input channel features
PAD (CH1, CH2) 26 dB
DSP
CH1: COMP/EQ, VOICE CHANGER, REVERB, MUTE
CH2: COMP/EQ, AMP SIM, REVERB, MUTE
CH 3/4, 5/6, 7/8: DUCKER, MUTE
PEAK LED Red LED lights up when signal level is 3 dB below clipping level
Output channel
features
DSP
SOUND PAD
MAXIMIZER, CUE
Level meter USB OUTPUT level 2 × 6 segment LED meters
USB audio 8 IN / 14 OUT
USB Audio Class 2.0 compliant; sampling frequency up to 48 kHz; bit
depth: 24-bit
Phantom power voltage +48 V
FOOT SW INPUT MUTE, TAP TEMPO, VOICE EFFECT, OUTPUT DIMMER
Power requirements DC 12 V, 1.5 A / USB Type-C 5 V, 1.5 A
Power consumption 7.5 W
Dimensions (W × H × D) 290 mm × 88 mm × 222 mm
Net weight 2.2 kg
Included accessories
PA-150B AC adapter, USB 2.0 cable (1.5 m), Start Guide, Safety Guide,
WaveLab Cast Download Information, Cubase AI Download Information
Optional accessories FC5 foot switch
Operating temperature 0 to +40℃
*1 Measured with 22 kHz LPF.
*2 Measured with A-weighting filter.
*3 Measured with 1 kHz band pass filter.
