AUDIOGRAM 3 Owner’s Manual
Setup
Be sure to turn the PHANTOM
+48V switch (★) on when
using a phantom-powered
condenser microphone.
Microphone
Keyboard, etc.
Computer
Headphones
Audio system
To connect a device such as a
microphone:
To connect an instrument such
as an electric guitar or bass:
USB cable
Cubase AI
