En 28
Advanced speaker configuration
In addition to the basic speaker configuration (p.20), the unit also allows you to apply the following speaker configurations to enhance your system.
Using the four internal
amplifiers for front speakers to
have more high-quality sounds
(Example) (Example) (Example)
Bi-amp
connection
Combining with an external
power amplifier (Hi-Fi amplifier,
multichannel amplifier, etc.) to
build an extended system
Using the excess internal
amplifiers for stereo speakers
in another room
External power
amplifier
Main zone
Zone2
Bi-amp connection Power-amp channel expansion Multi-zone configuration
1 2 3 4 5 6 7 8 9 10 11

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha AVENTAGE RX-A3050 and is the answer not in the manual?

Yamaha AVENTAGE RX-A3050 Specifications

General IconGeneral
Channels9.2
Amplifier TypeDiscrete
Power Output (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)150 W
Rated Output Power (20Hz-20kHz, 2ch driven)150 W
HDMI Inputs8
HDMI Outputs2
Network ConnectivityEthernet, Wi-Fi
USB Input1
YPAO CalibrationYes
Maximum Effective Output Power (1kHz, 1ch driven)230 W
Surround Sound ProcessingDolby Atmos, DTS:X
Video Upscaling4K
Audio Inputs9
Audio Outputs2
Speaker Outputs11
Dimensions (W x H x D)435 x 192 x 474 mm
