En 46
Connect the supplied FM/AM antennas to the unit.
Fix the end of the FM antenna to a wall, and place the AM antenna on a flat surface.
Assembling the AM antenna
Connecting the AM antenna
• Unwind only the length of cable needed from the AM antenna unit.
• The wires of the AM antenna have no polarity.
4 Connecting the FM/AM antennas
HDMI OUT
ARC
(ZONE OUT)
1
2
HDMI
(1 BD/DVD)
AV 1 AV 2 AV 3 AV 4
(HDCP2.2)
AV 5 AV 6 AV 7
IN
R
R
L
AV 1 AV 2 AV 3 AV 4
AUDIO 1 AUDIO 2 AUDIO 3
(2 TV)
(1 BD/DVD)
OPTICAL
4
OPTICAL
3
COAXIAL COAXIAL
2
COAXIAL
1
PHONO
GND
FM
75Ω
ANTENNA
(
4 RADIO
)
OPTICAL
1
2
ZONE OUT/PRE OUT
ZONE 2/
F. PRESENCE
ZONE 3/
R. PRESENCE
SPEAKERS
SURROUND BACK SURROUND
ZONE 2/ZONE 3/R.PRESENCE
R
5
6
L R
R
L
L
SINGLE
AM
PRE OUT
SUBWOOFER
CENTER FRONT SURROUND SUR. BACK
(SINGLE) (FRONT)
(REAR)
EXTRA SP2
TRIGGER
OUT
1
2
12V 0.1A
MAX. TOTAL
Y
P
B PR
PRPB
Y
P
RPB
YPRPB
AV 1
COMPONENT VIDEO
A
AV 3
C
AV 2
B
MONITOR OUT/
ZONE OUT
Y
(HDCP2.2)
FM antenna
AM antenna
The unit (rear)
Hold down Insert Release
1 2 3 4 5 6 7 8 9 10 11

Yamaha AVENTAGE RX-A3050 Specifications

General

Channels	9.2
Amplifier Type	Discrete
Power Output (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)	150 W
Rated Output Power (20Hz-20kHz, 2ch driven)	150 W
HDMI Inputs	8
HDMI Outputs	2
Network Connectivity	Ethernet, Wi-Fi
USB Input	1
YPAO Calibration	Yes
Maximum Effective Output Power (1kHz, 1ch driven)	230 W
Surround Sound Processing	Dolby Atmos, DTS:X
Video Upscaling	4K
Audio Inputs	9
Audio Outputs	2
Speaker Outputs	11
Dimensions (W x H x D)	435 x 192 x 474 mm
