AX-596
1
■ SPECIFICATIONS
■ Power Section
Minimum RMS Output Power
8Ω, 20Hz to 20kHz, 0.015% THD 100W + 100W
Maximum Output Power (EIAJ)
1kHz, 10% THD
8Ω/6Ω 145W / 170W
Dynamic Power (IHF)
8/6/4/2Ω 140/170/220/290W
DIN Standard Output Power
4Ω, 1kHz, 0.7% THD 150W
IEC Output Power
8Ω, 1kHz, 0.015% THD 110W
Power Band Width
8Ω, 50W, 0.03% THD 10Hz to 50kHz
Damping Factor
8Ω, 20Hz to 20kHz 320
Frequency Response
20Hz to 20kHz 0 ±0.5dB
20Hz to 100kHz 0 +0.5, –3dB
Total Harmonic Distortion (20Hz to 20kHz)
CD/DVD to SP OUT (8Ω, 50W) 0.008%
Signal to Noise Ratio (IHF-A-Network)
CD/DVD (Input Shorted, CD/DVD DIRECT AMP ON) 110dB
PHONO (Input Shorted) 92dB
Residual Noise (IHF-A-Network)
CD/DVD DIRECT AMP ON 35µV
■ Control Section
Input Sensitivity / Impedance
CD/DVD etc. 150mV / 47kΩ
PHONO 2.5mV / 47kΩ
Output Level / Impedance
PRE OUT 1V / 1.2kΩ
REC OUT 150mV / 0.6kΩ
Headphone Jack Rated Output / Impedance
0.33V / 680Ω
Channel Separation
CD/DVD (Input 5.1kΩ Terminated) 1kHz/10kHz 65 / 50dB
Tone Control Characteristics
BASS ±10dB (20Hz)
TREBLE ±10dB (20kHz)
Continuous Loudness Control
Attenuation –30dB (1kHz)
■ General
Power Supply
U, C models AC120V, 60Hz
B, G models AC230V, 50Hz
A model AC240V, 50Hz
R, T models AC110/120/220/240V, 50/60Hz
Power Consumption
Approx. 220W
AC Outlets
3 switched outlets
U, C, G, R, T models 100W max, total
1 switched outlets
A, B models 100W max, total
Dimensions (W x H x D) 435 x 151 x 396mm
(17-1/8" x 5-15/16" x 15-9/16")
Weight
11.0 kg (23lbs. 5oz.)
Accessories
Remote Control Transmitter
Batteries
Color
Gold / Black / Titan
* Specifications subject to change without notice.
U ........ U.S.A. model C .... Canada model
G ........ European model B .... British model
A ........ Australia model T ..... China model
R ........ General model
• DIMENSIONS
