4. Remove the radiator cap.
1. Radiator cap
5. Remove the coolant reservoir cap.
1. Coolant reservoir cap
6. Disconnect the hose on the coolant reser-
voir side and drain the coolant from the
coolant reservoir.
1. Coolant reservoir hose
2. Coolant reservoir
7. After draining the coolant, thoroughly flush
the cooling system with clean tap water.
8. Replace the coolant drain bolt washers if
they are damaged, and then tighten the
coolant drain bolts to the specified torque.
8-11
