8-10
EBU00765
To change the coolant
1. Put the ATV on a level place.
2. Remove the radiator cover bolts, and then
remove the radiator cover.
1. Radiator cover
2. Radiator cover bolt (×3)
3. Place a container under the engine and
remove the coolant drain bolts.
1. Drain bolt (×2)
POTENTIAL HAZARD
Removing the radiator cap when the
engine and radiator are still hot.
WHAT CAN HAPPEN
You could be burned by hot fluid and
steam blown out under pressure.
HOW TO AVOID THE HAZARD
Wait for the engine to cool before
removing the radiator cap. Always use a
thick rag over the cap. Allow any
remaining pressure to escape before
completely removing the cap.
q
WARNING
