8-25
Adjusting the throttle cables
NOTE:
After the jet needle clip position is changed, the
throttle cables may need to be adjusted.
1. Move the throttle lever a few times.
2. Push the throttle lever forward until it
stops and hold it in this position.
3. Check through each carburetor window to
see if the punch mark on the throttle valve
is at the specified position.
1. Punch mark a. Specified position
4. If not, loosen the locknut and turn the
adjusting nut until the specified position is
obtained.
1. Locknut (×2) 2. Adjusting nut (×2)
5. Move the throttle lever a few times and
recheck the position.
6. Install the fuel tank, side cover, radiator
cover and air filter case cover.
7. Connect the fuel hoses.
8. Install the seat.
