NOTE:
A special wrench can be obtained at a
Yamaha dealer to make this adjustment.
3. The length of the spring (installed)
changes 1.5 mm (0.06 in) per turn of the
adjusting nut.
4. Tighten the locknut to the specified
torque.
cC
Always tighten the locknut against the
adjusting nut and tighten it to the specified
torque.
Tightening torque:
54 Nm (5.4 m0kgf, 39 ft0lbf)
A. Spring length
4-15
Measurement A:
Installed length:
Minimum (hard):213.5 mm (8.4 in)
Standard: 220.5 mm (8.7 in)
Maximum (soft): 228.5 mm (9.0 in)
