Yamaha BWS 2003 - Right View Component Identification

2
DESCRIPTION
Right view
2-2
11 1213 14 15 16 17
18
192021
11. Rear carrier (page 3-10)
12. Oil tank cap (page 3-5)
13. Fuel tank cap (page 3-5)
14. Storage compartment (page 3-8)
15. Main switch / steering lock (page 3-1)
16. Throttle grip (page 6-15)
17. Right handlebar switches (page 3-4)
18. Front brake lever (page 3-4)
19. Battery (fuse) (page 6-17 — 6-19)
20. Securing bracket (page 3-11)
21. Centerstand (page 6-15)
