3
INSTRUMENT AND CONTROL FUNCTIONS
1. Speedometer
2. Odometer
1. Fuel gauge
EAU00098
Speedometer unit
The speedometer unit is equipped with
a speedometer and an odometer. The
speedometer shows riding speed. The
odometer shows the total distance
traveled.
EAU00113
Fuel gauge
The fuel gauge indicates the amount
of fuel in the fuel tank. The needle
moves towards "E" (Empty) as the fuel
level decreases. When the needle
reaches "E", refuel as soon as possi-
ble.
NOTE :
Do not allow the fuel tank to empty itself
completely.
3-3
1
ZAUM0178
1
2
1
2
ZAUM0177
UK ONLY
