Yamaha CRX-E500 - Test Mode

CDC-E500
CDC-E500
24
STANDBY/ON Key is pressed while pressing STOP Key and PLAY/PAUSE Key.
TEST MODE indication.
Key
Test mode number up. Test mode number down.
Key DISC SKIP Key
Execute test mode.
STANDBY/ON Key
POWER OFF
The completion
of test mode.
POWER Off condition
TEST MODE UP TEST MODE DOWN When pressed, mode is carried out.
Test mode is finished.
Disconnect the
power cord.
■ TEST MODE
TEST PROGRAM MODE FUNCTION DESCRIPTION
Command Function
00:Op/Cl The tray closes if it is open, and the tray opens if it is closed.
Don't carry it out during opening or closing.
01:AT Adj-1 Automatic adjustment 1 (Tracking offset adjustment / Focus offset adjustment / Standby)
02:AT Adj-2 Automatic adjustment 2 (Focus On, Tracking Off / Focus gain approximate adjustment / Standby / Focus
search / Disc spin / Focus On, Tracking On / Servo On / EF balance adjustment / Tracking gain
approximate adjustment)
03:AT Adj-3 Automatic adjustment 3 (Focus gain precise adjustment / Tracking gain precise adjustment / Focus
balance adjustment
04:TRV Rev Traverse unit moves toward the inside.
05:TRV Fwd Traverse unit moves toward the outside.
06:TRV Stop Traverse unit stops.
07:SP Accel Spindle motor acceleration.
08:SP Brake Spindle motor brake.
09:SP S On Spindle servo On.
10:SP S Off Spindle servo Off.
11:SP Stop Spindle motor stop (include 8 sec. waiting).
12:FCS SRH Focus On, Tracking Off.
13:Tr&Tv Off Focus On, Tracking Off, Feed Off.
14:1 Kick R 1 Kick in the inside direction is repeated every 30msec.
15:1 Kick F 1 Kick in the outside direction is repeated every 30msec.
