■ CDC-MECHANISM REPAIRING PROCEDURES
1. Explanation of part names and terms.
Front/rear: With the mechanism installed normally, the drawer opening direction is to the front.
Top/bottom: With the mechanism installed normally, the drawer is visible from the top.
Photo 1
Slider 1
Arm Stopper B Arm Clamper Carriage Bevel Gear
Gear Idler A Slider 2 Bevel Gear 1 Drawer
RightLeft
Front: drawer opening direction
