EAB90101
Rear brake pedal
The rear brake pedal is on the right side of
the motorcycle. Press down on the brake
pedal to apply the rear brake.
EAC01300*
Fuel tank cap
To add fuel, open the seat. Then remove
the fuel tank cap by turning it counterclock-
wise.
(See page 20 to open the seat.)
17
1 Rear brake pedal
1 Fuel tank cap
T105(E) O/M-1 9/11/01 11:16 AM Page 17 (1,1)
