Air filter
1. Remove the front panel and the
legshield by removing the screws.
2. Remove the air filter case fitting
screws and the filter case cover.
3. Remove the air filter element from its
case, and clean it with solvent. After
cleaning, remove the remaining sol-
vent by squeezing the element.
44
1 Air filter case cover 2 Screw (4 pcs)
1 Air filter element
