Drive chain slack adjustment
1. Loosen the rear brake adjuster.
2. Loosen the axle nut.
3. Loosen the sprocket shaft nut and the
axle nut.
4. To tighten the chain, turn the chain ad-
juster clockwise. To loosen the chain,
turn the adjuster counterclockwise and
push the wheel forward. Turn each ad-
juster exactly the same amount to main-
tain correct axle alignment. There are
marks on each side of the swingarm and
a match mark on each chain puller. Use
these marks to align the rear wheel.
EUU33301
cC
Too little chain slack will overload the en-
gine and other vital parts. Keep the slack
within the specified limits.
54
1 Rear brake adjuster 2 Axle nut
1 Axle nut 2 Sprocket shaft nut
3 Chain puller 4 Chain adjuster
