Yamaha CS1X Data List

Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
60 00 50 1 00...7F MW Filter Control -64...+63 40(+0)
51 1 00...7F MW LFO PMod Depth 0...127 0A(10)
52 1 00...7F MW LFO FMod Depth 0...127 0
53 1 28...58 Bend Pitch Control -24...+24(semitones) 42(+2semitones)
54 1 00...7F FC Filter Control -64...+63 40(+0)
55 1 00 reserved 0 00
56 1 00...7F FC LFO FMod Depth 0...127 0
57 1 00...01 Portamento Switch off(0),on(1) 0(off)
58 1 00...7F Portamento Time 0...127 0
Total size 09
MIDI Data Table <2-4>
MIDI Parameter Change table ( Current Performance Layer)
Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
60 0L 00 1 00...7F Voice Bank Number MSB 0...127 00
01 1 00...7F Voice Bank Number LSB 0...127 00
02 1 00...7F Voice Number 1...128 00
03 1 00...03 Play Mode mono(0),poly(1) 1(poly)
04 1 28...58 Note Shift -24...+24(semitones) 40(+0)
05 2 00...FF Detune -12.8...+12.7(Hz) 08(+0.0Hz)
1st bit3...0 >> bit7...4 00
07 1 00...7F Volume 0...127 64(100)
08 1 00...7F Velocity Sense Depth 0...127 40(64)
09 1 00...7F Velocity Sens Offset -64...+63 40(+0)
0a 1 00...7F Pan random(0),L63...C...R63 40(C)
0b 1 00...7F Note Limit Low C-2...G8 00(C-2)
0c 1 00...7F Note Limit High C-2...G8 7F(G8)
0d 1 00...7F Chorus Send 0...127 00
0e 1 00...7F Reverb Send 0...127 28(40)
0f 1 00...7F Variation Send off(0),on(1...127) 7F(on)
10 1 00...02 LFO Key Sync FreeRun(0),retrigger(1),-(2) 2(-)
11 1 00...7F Filter Cutoff Freq. -64...+63 40(+0)
12 1 01...7F Filter Resonance -63...+63 40(+0)
13 1 01...7F Amp. EG Attack Time -63...+63 40(+0)
14 1 01...7F Amp. EG Decay Time -63...+63 40(+0)
15 1 01...7F Amp. EG Release Time -63...+63 40(+0)
16 1 00...03 Receive Note(Mute) off(0),on(1) 1(on)
17 1 00...7F PitchEG Initial Level -64...+63 40(+0)
18 1 01...7F PitchEG Attack Time -63...+63 40(+0)
19 1 01...7F PitchEG Release Time -63...+63 40(+0)
1a 1 00...7F PitchEG Release Level -64...+63 40(+0)
1b 1 01...7F Velocity Limit Low 1...127 01
1c 1 01...7F Velocity Limit High 1...127 7F(127)
1d 1 00...7F Amp. EG Sustain Level -64...+63 40(+0)
1e 1 01...7F LFO Speed -63...+63 40(+0)
1f 1 00...7F LFO Wave 0...3(saw,tri,S&H,--) 3(--)
20 1 21...5F LFO AMod Depth -31...+31 40(+0)
21 1 01...7F LFO PMod Depth -63...+63 40(+0)
22 1 31...4F LFO FMod Depth -15...+15 40(+0)
23 1 01...7F FilterEG Attack Time -63...+63 40(+0)
24 1 01...7F FilterEG Decay Time -63...+63 40(+0)
25 1 00...7F FilterEG Sus Level -64...+63 40(+0)
26 1 01...7F FilterEG Release Time -63...+63 40(+0)
27 1 00...7F PitchEG Attack Level -64...+63 40(+0)
28 1 01...7F PitchEG Decay Time -63...+63 40(+0)
Total size 29
l =1 ;Layer1
2 ;Layer2
3 ;Layer3
4 ;Layert4
MIDI Data Table <2-5>
MIDI Parameter Change table ( User Performance Common)
Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
70 pp 00 1 20...7F Performance Name 1 Ascii Code I
01 1 20...7F Performance Name 2 Ascii Coden
02 1 20...7F Performance Name 3 Ascii Codei
03 1 20...7F Performance Name 4 Ascii Codet
04 1 20...7F Performance Name 5 Ascii CodeP
05 1 20...7F Performance Name 6 Ascii Codee
06 1 20...7F Performance Name 7 Ascii Coder
07 1 20...7F Performance Name 8 Ascii Codef
08 1 00...54 Performance Category --,Pf...Wv--
09 1 00...7F Common Volume 0...127 64(100)
0a 1 00...7F Scene1 For Knob1 -64...+63 40(+0)
0b 1 00...7F Scene1 For Knob2 -64...+63 40(+0)
0c 1 00...7F Scene1 For Knob3 -64...+63 40(+0)
0d 1 00...7F Scene1 For Knob4 -64...+63 40(+0)
0e 1 00...7F Scene1 For Knob5 -64...+63 40(+0)
0f 1 00...7F Scene1 For Knob6 -64...+63 40(+0)
10 1 00...7F Scene2 For Knob1 -64...+63 40(+0)
11 1 00...7F Scene2 For Knob2 -64...+63 40(+0)
12 1 00...7F Scene2 For Knob3 -64...+63 40(+0)
13 1 00...7F Scene2 For Knob4 -64...+63 40(+0)
14 1 00...7F Scene2 For Knob5 -64...+63 40(+0)
15 1 00...7F Scene2 For Knob6 -64...+63 40(+0)
16 1 00...7F Knob1 Value -64...+63 40(+0)
17 1 00...7F Knob2 Value -64...+63 40(+0)
18 1 00...7F Knob3 Value -64...+63 40(+0)
19 1 00...7F Knob4 Value -64...+63 40(+0)
1a 1 00...7F Knob5 Value -64...+63 40(+0)
1b 1 00...7F Knob6 Value -64...+63 40(+0)
1c 2 00...04 Knob6 Parameter1 MSB layer1(0)...4(3) 00(layer1)
00...1E Knob6 Parameter1 LSB off(0),1...29 00(off)
1e 2 00...04 Knob6 Parameter2 MSB layer1(0)...4(3) 01(layer2)
00...1E Knob6 Parameter2 LSB 0(off),1...29 00(off)
20 2 00...04 Knob6 Parameter3 MSB layer1(0)...4(3) 02(layer3)
00...1E Knob6 Parameter3 LSB 0(off),1...29 00(off)
22 2 00...04 Knob6 Parameter4 MSB layer1(0)...4(3) 03(layer4)
00...1E Knob6 Parameter4 LSB 0(off),1...29 00(off)
24 1 20...60 Knob6 Sensitivity1 -32...+32 40(+0)
25 1 20...60 Knob6 Sensitivity2 -32...+32 40(+0)
26 1 20...60 Knob6 Sensitivity3 -32...+32 40(+0)
27 1 20...60 Knob6 Sensitivity4 -32...+32 40(+0)
28 1 00...10 Knob3 Parameter off(0),1...16 00(off)
29 1 00...01 Arpeggiator Tempo MSB 0(MIDI),40(1)..240(201) 00 65(140)
00...7F Arpeggiator Tempo LSB
2b 1 00...17 Arpeggiator Type 0(Up1Oct)...31(special17) 09(UpDnB1Oct)
2c 1 00...09 Arpggiator Subdivide 0(3/8)...9(1/32) 07(1/16)
2d 1 00...05 Arpeggiator On/Off 0(off)/1(on)/2(hold) 00(off,split on)
bit2=split on/off
Total size 2e
Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
70 pp 30 2 00...7F Reverb Type MSB See Effect Type List 01(=Hall)
00...7F Reverb Type LSB 00:basic type 00(basic)
32 2 00...7F Chorus Type MSB See Effect Type List 41(=Chorus1)
00...7F Chorus Tyle LSB 00:basic type 00(basic)
34 2 00...7F Vari. Type MSB See Effect Type List 05(=Delay L,C,R)
00...7F Vari. Type LSB 00:basic type 00(basic)
36 2 00...7F Vari. Param 1 MSB See Effect Parameter List Depends On Vari. Type
00...7F Vari. Param 1 LSB See Effect Parameter List Depends On Variation Type
38 2 00...7F Vari. Param 2 MSB See Effect Parameter List Depends On Variation Type
00...7F Vari. Param 2 LSB See Effect Parameter List Depends On Variation Type
3a 2 00...7F Vari. Param 3 MSB See Effect Parameter List Depends On Variation Type
00...7F Vari. Param 3 LSB See Effect Parameter List Depends On Variation Type
3c 2 00...7F Vari. Param 4 MSB See Effect Parameter List Depends On Variation Type
00...7F Vari. Param 4 LSB See Effect Parameter List Depends On Variation Type
3e 2 00...7F Vari. Param 5 MSB See Effect Parameter List Depends On Variation Type
00...7F Vari. Param 5 LSB See Effect Parameter List Depends On Variation Type
40 2 00...7F Vari. Param 10 MSB See Effect Parameter List Depends On Variation Type
00...7F Vari. Param 10 LSB See Effect Parameter List Depends On Variation Type
42 1 40 reserved 64 40
43 1 00...7F FC Vari. Cntrl Depth -64...+63 40(+0)
44 1 00...7F Send Chorus To Reverb 0...127 0
Total size 15
Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
70 pp 50 1 00...7F MW Filter Control -64...+63 40(+0)
51 1 00...7F MW LFO PMod Depth 0...127 0A(10)
52 1 00...7F MW LFO FMod Depth 0...127 0
53 1 28...58 Bend Pitch Control -24...+24(semitones) 42(+2semitones)
54 1 00...7F FC Filter Control -64...+63 40(+0)
55 1 00 reserved 0 00
56 1 00...7F FC LFO FMod Depth 0...127 0
57 1 00...01 Portamento Switch off(0),on(1) 0(off)
58 1 00...7F Portamento Time 0...127 0
Total size 09
pp = Performance Number(00...7F)
MIDI Data Table <2-6>
MIDI Parameter Change table ( Current Performance Layer)
Address Size Data Prameter Name Description Default
(H) (H) (H) Value(H)
7l pp 00 1 00...7F Voice Bank Number MSB 0...127 00
01 1 00...7F Voice Bank Number LSB 0...127 00
02 1 00...7F Voice Number 1...128 00
03 1 00...03 Play Mode mono(0),poly(1) 1(poly)
04 1 28...58 Note Shift -24...+24(semitones) 40(+0)
05 2 00...FF Detune -12.8...+12.7(Hz) 08(+0.0Hz)
1st bit3...0 >> bit7...4 00
07 1 00...7F Volume 0...127 64(100)
08 1 00...7F Velocity Sense Depth 0...127 40(64)
09 1 00...7F Velocity Sens Offset -64...+63 40(+0)
0a 1 00...7F Pan random(0),L63...C...R63 40(C)
0b 1 00...7F Note Limit Low C-2...G8 00(C-2)
0c 1 00...7F Note Limit High C-2...G8 7F(G8)
0d 1 00...7F Chorus Send 0...127 00
0e 1 00...7F Reverb Send 0...127 28(40)
0f 1 00...7F Variation Send off(0),on(1...127) 7F(on)
10 1 00...02 LFO Key Sync FreeRun(0),retrigger(1),-(2) 2(-)
11 1 00...7F Filter Cutoff Freq. -64...+63 40(+0)
12 1 01...7F Filter Resonance -63...+63 40(+0)
13 1 01...7F Amp. EG Attack Time -63...+63 40(+0)
14 1 01...7F Amp. EG Decay Time -63...+63 40(+0)
15 1 01...7F Amp. EG Release Time -63...+63 40(+0)
16 1 00...03 Receive Note(Mute) off(0),on(1) 1(on)
17 1 00...7F PitchEG Initial Level -64...+63 40(+0)
18 1 01...7F PitchEG Attack Time -63...+63 40(+0)
19 1 01...7F PitchEG Release Time -63...+63 40(+0)
1a 1 00...7F PitchEG Release Level -64...+63 40(+0)
1b 1 01...7F Velocity Limit Low 1...127 01
1c 1 01...7F Velocity Limit High 1...127 7F(127)
1d 1 00...7F Amp. EG Sustain Level -64...+63 40(+0)
1e 1 01...7F LFO Speed -63...+63 40(+0)
1f 1 00...7F LFO Wave 0...3(saw,tri,S&H,--) 3(--)
20 1 21...5F LFO AMod Depth -31...+31 40(+0)
21 1 01...7F LFO PMod Depth -63...+63 40(+0)
22 1 31...4F LFO FMod Depth -15...+15 40(+0)
23 1 01...7F FilterEG Attack Time -63...+63 40(+0)
24 1 01...7F FilterEG Decay Time -63...+63 40(+0)
25 1 00...7F FilterEG Sus Level -64...+63 40(+0)
26 1 01...7F FilterEG Release Time -63...+63 40(+0)
27 1 00...7F PitchEG Attack Level -64...+63 40(+0)
28 1 01...7F PitchEG Decay Time -63...+63 40(+0)
Total size 29
pp = Performance Number(00...7F)
l = 1 ;Layer1
2 ;Layer2
3 ;Layer3
4 ;Layert4
25
MIDIDataFormat
CS1xリストブック2(E)97.7.176:23PMページ25

Yamaha CS1X Specifications

General

Polyphony	32 voices
Oscillators	2 per voice
Effects	Reverb, Chorus, Variation
Control	Pitch Bend, Modulation Wheel
Year Released	1996
Synthesis Type	AWM2 (Advanced Wave Memory 2)
Multitimbral	16 parts
MIDI	In, Out, Thru
Sequencer	No
Arpeggiator	Yes
Keyboard	61 keys
Outputs	L/Mono, R
Memory	128 user patches, 128 preset patches
Weight	7.5 kg
Type	Digital Synthesizer
ROM	8MB Wave ROM
Filters	Resonant Filters
