Yamaha CS1X User Manual

50
The parameter depth marked with a ● can be controlled
by the ASSIGN 1 Sound Control Knob or Foot Controller when properly
assigned.
The parameter numbers at far left correspond to the parameter suffix
numbers in MIDI Data Table <1-4> (MIDI Data Format) in the "Data
List" book.
NOTE
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Phase Shift Offset 0~127 0-127
4 Feedback Level -63~+63 1-127
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11 Stage 6~10(phaser1) / 3~5(phaser2) 3-10
12 Diffusion Mono/Stereo 0-1
13 LFO Phase Difference -180~+180deg. 4-124 Phaser2
14
15
16
No. Parameter Display Value See Table Control
PHASER1, PHASER2
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 ●
2 L/R Depth 0~127 0-127
3 F/R Depth 0~127 0-127
4 PAN Direction L<->R,L->R,L<-R,Lturn,Rturn,L/R 0-5
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
AUTO PAN
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 ●
2 AM Depth 0~127 0-127
3 PM Depth 0~127 0-127
4
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11
12
13
14 LFO Phase Difference -180~+180deg 4-124 resolution=3deg.
15 Input Mode mono/stereo 0-1
16
No. Parameter Display Value See Table Control
TREMOLO
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 ●
2 LFO Depth 0~127 0-127
3
4
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13
14
15
16
No. Parameter Display Value See Table Control
ROTARY SPEAKER
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Delay Offset 0.0~50.0ms 0-127 table#2
4
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
SYMPHONIC
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0.0~6.3ms 0-63 table#2
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11
12
13
14 LFO Phase Difference -180~+180deg 4-124 resolution=3deg.
15
16
No. Parameter Display Value See Table Control
FLANGER1,FLANGER2,FLANGER3
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO PM Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0.0~50.0ms 0-127 table#2
5
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11
12
13
14
15 Input Mode mono/stereo 0-1
16
No. Parameter Display Value See Table Control
CHORUS1,2,3,4, CELESTE1,2,3,4
1 Delay Time 0~400.0ms 0-127 table#7
2 Feedback Level -63~+63 1-127
3 HPF Cutoff Thru~8.0kHz 0-52
4 LPF Cutoff 1.0k~Thru 34-60
5
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
KARAOKE1,2,3
1 Type TypeA,TypeB 0-1
2 Room Size 0.1~7.0 0-44 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1~99.3ms 0-63 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52
7 LPF Cutoff 1.0k~Thru 34-60
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
No. Parameter Display Value See Table Control
GATE REVERB,REVERSE GATE
1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0-5
2 Room Size 0.1~7.0 0-44 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1~99.3ms 0-63 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52
7 LPF Cutoff 1.0k~Thru 34-60
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127 ●
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
No. Parameter Display Value See Table Control
EARLY REF1,EARLY REF2

Yamaha CS1X Specifications

General

Polyphony	32 voices
Oscillators	2 per voice
Effects	Reverb, Chorus, Variation
Control	Pitch Bend, Modulation Wheel
Year Released	1996
Synthesis Type	AWM2 (Advanced Wave Memory 2)
Multitimbral	16 parts
MIDI	In, Out, Thru
Sequencer	No
Arpeggiator	Yes
Keyboard	61 keys
Outputs	L/Mono, R
Memory	128 user patches, 128 preset patches
Weight	7.5 kg
Type	Digital Synthesizer
ROM	8MB Wave ROM
Filters	Resonant Filters
