Yamaha CS2x Data List

22
Effect Parameter List
NO.
CHORUS1,2,3,4
CELESTE1,2,3,4 (chorus, variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LFO Frequency
LFO Depth
Feedback Level
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry/Wet
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode
0.00Hz~39.7Hz
0~127
-63~+63
0~50.0
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
D63>W ~ D=W ~ D<W63
100Hz~10.0kHz (variation block)
-12~+12dB (variation block)
1.0~12.0 (variation block)
mono/stereo
0-127
0-127
1-127
0-127
4-40
52-76
28-58
52-76
1-127
14-54
52-76
10-120
0-1
table#1
table#2
table#3
table#3
table#3
NO.
KARAOKE1,2,3 (variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Delay Time
Feedback Level
HPF Cutoff
LPF Cutoff
Dry/Wet
0.1~400ms
-63~+63
Thru~8.0kHz
1.0k~Thru
D63>W ~ D=W ~ D<W63
0-127
1-127
0-52
34-60
1-127
table#7
table#3
table#3
NO.
GATE REVERB
REVERSE GATE (variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Type
Room Size
Diffusion
Initial Delay
Feedback Level
HPF Cutoff
LPF Cutoff
Dry/Wet
Liveness
Density
High Damp
TypeA,TypeB
0.1~20.0
0~10
0.1~99.3ms
-63~+63
Thru~8.0kHz
1.0k~Thru
D63>W ~ D=W ~ D<W63
0~10
0~3
0.1~1.0
0-1
0-127
0-10
0-63
1-127
0-52
34-60
1-127
0-10
0-3
1-10
table#6
table#5
table#3
table#3
NO.
EARLY REF1,EARLY REF2(variation block)
Parameter Display Value ControlSee Table
table#6
table#5
table#3
table#3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Type
Room Size
Diffusion
Initial Delay
Feedback Level
HPF Cutoff
LPF Cutoff
Dry/Wet
Liveness
Density
High Damp
S-H, L-H, Rdm, Rvs, Plt, Spr
0.1~7.0
0~10
0.1~99.3ms
-63~+63
Thru~8.0kHz
1.0k~Thru
D63>W ~ D=W ~ D<W63
0~10
0~3
0.1~1.0
0-5
0-44
0-10
0-63
1-127
0-52
34-60
1-127
0-10
0-3
1-10
table#6
table#5
table#3
table#3
NO.
CROSS DELAY (variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
L->R Delay
R->L Delay
Feedback Level
Input Select
High Damp
Dry/Wet
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1~743.0ms
0.1~743.0ms
-63~+63
L,R,L&R
0.1~1.0
D63>W ~ D=W ~ D<W63
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
1-7430
1-7430
1-127
0-2
1-10
1-127
4-40
52-76
28-58
52-76
table#3
table#3
NO.
ROTARY SPEAKER (variation block)
Parameter Display Value ControlSee Table
●1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LFO Frequency
LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry/Wet
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
0.00Hz~39.7Hz
0~127
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
D63>W ~ D=W ~ D<W63
100Hz~10.0kHz
-12~+12dB
1.0~12.0
0-127
0-127
4-40
52-76
28-58
52-76
1-127
14-54
52-76
10-120
table#1
table#3
table#3
table#3
NO.
AMBIENCE (variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Delay Time
Output Phase
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry/Wet
0~50.0
normal / inverse
normal / inverse
-63~+63
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
D63>W ~ D=W ~ D<W63
0-127
0-1
4-40
52-76
28-58
52-76
1-127
table#2
table#3
table#3
NO.
ENSEMBLE DETUNE (chorus, variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Detune
Lch Init Delay
Rch Init Delay
Dry/Wet
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
-50~+50cent
0~50.0
0~50.0
D63>W ~ D=W ~ D<W63
32Hz~2.0kHz (variation block)
-12~+12dB (variation block)
500Hz~16.0kHz (variation block)
-12~+12dB (variation block)
14-114
0-127
0-127
1-127
4-40
52-76
28-58
52-76
table#2
table#2
table#3
table#3
NO.
SYMPHONIC (chorus, variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LFO Frequency
LFO Depth
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry/Wet
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
0.00Hz~39.7Hz
0~127
0~50.0
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
D63>W ~ D=W ~ D<W63
100Hz~10.0kHz (variation block)
-12~+12dB (variation block)
1.0~12.0 (variation block)
0-127
0-127
0-127
4-40
52-76
28-58
52-76
1-127
14-54
52-76
10-120
table#1
table#2
table#3
table#3
table#3
NO.
FLANGER1,2,3 (chorus, variation block)
Parameter Display Value ControlSee Table
●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LFO Frequency
LFO Depth
Feedback Level
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry/Wet
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
LFO Phase Difference
0.00Hz~39.7Hz
0~127
-63~+63
0~50.0
32Hz~2.0kHz
-12~+12dB
500Hz~16.0kHz
-12~+12dB
D63>W ~ D=W ~ D<W63
100Hz~10.0kHz (variation block)
-12~+12dB (variation block)
1.0~12.0 (variation block)
-180~+180deg
0-127
0-127
1-127
0-127
4-40
52-76
28-58
52-76
1-127
14-54
52-76
10-120
4-124
table#1
table#2
table#3
table#3
table#3
resolution=
3deg.
DL_Multi.qx 2/2/99 7:46 PM Page 22

Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
