Specifications 11
DA824—Owner’s Manual
Analog Output
Digital I/O
Connection GAIN SW
Actual
Source
Impedance
For Use
with
Nominal
Output Level
Connector
Nominal
Max.
before clip
OUTPUT 1–8
1
1. 24-bit 128-times oversampling D/A converters.
+24 dB
150 Ω lines 600 Ω lines
+10 dB
(2.45 V)
+24 dB
(12.28 V)
XLR-3-32
type
(balanced)
2
&
TRS phone
jack
(balanced)
3
2. XLR-type connectors are electronically balanced (pin 1 = ground, pin 2 = hot, pin 3 = cold).
3. TRS phone jacks are electronically balanced (tip = hot, ring = cold, sleeve = ground).
* Where dB represents a specific voltage, 0 dB is referenced to 0.775 V rms, 0 dBV is refer-
enced to 1.00 V rms.
+18 dB
+4 dB
(1.23 V)
+18 dB
(6.16 V)
+15 dB
+1 dB
(0.87 V)
+15 dB
(4.36 V)
+4 dBV
–10 dBV
(0.316 V)
+4 dBV
(1.58 V)
Connection Format Level/Impedance Connector
COM — RS232C 9-pin D-sub (male)
WORD CLOCK IN — TTL, 75Ω (ON/OFF) BNC
WORD CLOCK THRU — TTL, 75Ω BNC
SLOT mini YGDAI — —
