Yamaha DD-50 - Side Panel Controls; Connecting the Foot Pedals; Supplied Accessories

5
Control Panel
)
q
Side Panel (Left)
* DC IN 10-12V (AC Adaptor) Jack ..................3
( PHONES/AUX OUT Jack ..............................3
Side Panel (Right)
) MIDI IN/MIDI OUT Terminals .......................16
q PEDAL 1/2 Jacks ...........................................5
@
MIDI IN
MIDI OUT
PEDAL 1
PEDAL 2
DEMO DD-50
BREAK/
TAPSTART
START/
STOP
A-B
REPEAT
R
E
C
.
#
$
%
^
Connecting the Foot Pedals (1/2)
The supplied foot pedals can be connected to the
DD-50 to similarly play the drum set’s hi-hat
pedal or bass drum voices or they can also be
assigned to play other voices as well.
• Do not press the pedal while connecting
it to the DD-50 or while turning on the
power. (Connecting in this manner with
the power on, the pedal’s function may
be reversed.)
● Supplied Accessories
Foot Pedal x 2
Drum Stick x 2
Owner’s Manual
