Yamaha DE-DHT - Symbols; Chapter Thumb-Tabs; Specific Information Symbols; Lubrication Symbols

SYMBOLS
Symbols 1 to 0 are designed as thumb-tabs
and indicate the content of a chapter.
1 General information
2 Specification
3 Periodic inspection and adjustment
4 Upper unit housing
5 6U41 Lower unit housing
6 6U51 Lower unit housing
7 Intermediate assembly
8 Steering system
9 Power trim system
0 Tr o u bl e s ho o t ing
Symbols A to H indicate specific informa-
tion:
A Special tool
B Recommended fuel
C Lubricant
D Engine speed
E Tightening torque
F Specified value, measure, limit
G Press load
H Resistance (Ω), voltage (V), electric cur-
rent (A)
Symbols I to K in an exploded diagram in-
dicate grade of lubricant and location of lu-
brication point:
I Apply Yamaha gear-case lubricant
J Apply water resistant grease
(Yamaha marine grease A)
K Apply corrosion resistant grease
(Yamaha marine grease D)
Symbols L and M in an exploded diagram
indicate grade of sealing or locking agent,
and location of application point:
L Apply LOCTITE
®
No. 271, 242, 572,1829
or 1501
M Apply ThreeBond
®
TB-1322, 1324, 1524
or 1501
