Yamaha Disklavier MX-100B - Electrical Parts

MX-100B
Electrical Parts
1
* New Parts
Ref.
No. Part No.
Description
Remarks
Control Unit
VJ580100
XF750A00
iT520500
XA591001
XA457001
iG132700
iG057300
iG137800
XA513002
iG067210
iG068100
iG096700
iG057400
iG044200
iG049900
iG060000
iG044600
iG050100
iG044000
iG060200
iG050300
iG044400
iG049600
iG049800
iG043700
iG027010
iG026910
iG050000
iG059100
iG152700
iG044500
iG116200
iG063500
XH900A00
XH901A00
VG181900
HL324150
HL324680
HL314330
VB350500
VB350600
HZ003350
HZ002940
HZ003370
HZ003380
FZ004100
iC181520
VA106500
HT370010
VD017000
QU001400
QU003500
FZ006970
Circuit Board, CPU
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
Photo Coupller
Metal Oxide Film Resistor
Metal Oxide Film Resistor
Metai Oxide Film Resistor
Resistor Array
Resistor Array
Resistor Array
Resistor Array
Resistor Array
Resistor Array
Semi-Conductive Cera. Cap.
Trnsistor
Diode
Semi-Variable Resistor
DIP Switch
Quartz Crystal
Ceramic Resonator
EMI Filter
RP65C02G
YM5205
YM3802
MB81464-12
HD6350
MB8877
FDC9216B
M50760-463
TC4511BP
TC40H240
TC40H175
F9602
LS138
LS139
LS244
LS245
LS175
LS74
LS273
LS293
LS161
LS14
LS32
LS08
LS04
LS00
LS174
SN74LS06N
MB74LS07P
LS240
PST518
NJM555
256K
128K
PC900V
15Ω2W
65Ω2W
33Ω 1W
470 Ω X8
1KΩX8
4.7K Ω X4
4.7K Ω X8
10K Ω X4
10K Ω X8
0.1A µ F16V
2SC1815
1SS176
B1K Ω
51D-0401
8MHz
CSB400MT
0.022 µ F
CPU
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
CPU →iT202500
PMAC
MCS
RAM(64kX4bit)
ACIA
FDC
Data Separater
RMCN Decoder
BCD to 7 Latch
OCT.Buff. Inverter
Quad. D F-F.
Multi Vibrator
3 to 8 Decoder
Dual 2-4 Decoder
Oct. Bus Driver
Oct. Tranceiver
Quad. D F-F.
Edge Trigger
Oct. D F-F.
4bit Counter
4bit Counter
Hex Schmitt Trigger
Quad 2 IN NOR
Quad 2 IN AND
Hex Inverter
Quad 2 IN NAND
Hex D F-F.
Hex Inverter
Hex Buffer
Oct Buffer
Reset IC
Timer
ROM A
ROM B
