Yamaha Disklavier MX-100B - Key Drive Unit (West German Model)

MX-100B
3. Key Drive Unit (West German Model)
13
Ref.
No.
1
2
3
4
5
6
7
8
9
10
10
10
10
11
Part No.
VH590200
EA040556
EX550110
EB040186
VG927000
VG925300
VG925400
VG915200
VG915300
VG927100
VG927200
VG967300
VG967400
ED030066
Description
Key Drive Unit
Pan Head Screw
Insert Nut
Flat Head Screw
Bushing, Spring
Cushion Spring (A)
Cushion Spring (B)
Circuit Board, Drive (B)
Circuit Board, Drive (C)
Coil Ass'y (A)
Coil Ass'y (B)
Coil Ass'y (AL)
Coil Ass'y (BL)
Bind Head Screw
4X55 YE
B4X9.5 YE
4X18 YE
18mm WH
22mm YE
24Key
16Key
=60 BL
=35 WH
=75 BL
=50 WH
3X6 YE
Remarks
Rear
Front
ODD Key
EVEN Key
Key# 1,17,39
Key# 40
