Yamaha Disklavier MX-100B - Page 32

MX-100B
4
Ref.
No. Part No.
iG036100
VB434400
VB433900
HZ003190
HV753470
FZ005030
CB502590
LB918090
LB918110
Description
IC
Photo Diode
Resistor Array
Resistor Array
Frame Ploof Carbon Resistor
Semi-Conductive Cera. Cap.
Socket
Connector XH Type, Top
Connector XH Type, Top
NJM2901
S2506-02
33K Ω
4.7K Ω
4.7 Ω 1/4W
0.1 µ F/25V
9P
11P
VG392200 Pedal Drive Unit
VH590400 Pedal Drive Unit
iD102300
VB481900
VH407900
VH648700
NB037050
Transistor
Diode
Mute Motor Ass'y
Motor, Mute
Tablet Switch
2SD1023
11ES4
M
NB513260 Pedal Sensor Unit
NB137040 PK Switch
1T
I/O Unit
VH065000
iT202000
iG027010
iG043700
iG049800
iG036100
XG275A00
iG057400
iC181520
iD102300
VB293700
HZ002940
VB307500
VB307600
VA106500
VB295700
iF001840
iF001220
FZ004100
FP337100
FZ000680
iF008530
VB293300
VB293400
Circuit Board, I/O
IC
IC
IC
IC
IC
IC
IC
Transistor
Transistor
Transistor Array
Resistor Array
Resistor Array
Resistor Array
Diode
Diode Array
Zener Diode
First Recocvery Diode
Semi-Conductive Cera. Cap.
Tantalum Capacitor
MM Capacitor
LED
Ceramic Resonator
Relay
YM2020 PWM
HD74LS04P
HD74LS08P
HD74LS32
NJM2901
TC74HC4538AP
F9602
2SC1815
2SD1023
TH3L20
4.7 Ω
100K Ω
1M Ω
1SS176
DAP-801
RD3.0EB
S2K20
0.1 µ F16V
10 µ F16V
0.1 µ F250V
GL-IHD201
CSA4.0MG11
G6A-274P DC5V
IC
Remarks
U, C, B, E, A
WG
WG
WG
U, C, B, E, A
Digital PWM
Hex Inverter
Quad 2in AND
Quad 2in NOR
Quad Comparator
Multi Vibrator
RM8-472
RM8-104
RM8-105
IC
IC
IC
IC
IC
IC
IC
PK
