I-8
5. Controller
All Disklavier models include a control unit (controller). The controller implementation has changed over time, as
controllers have gradually become smaller and increasingly functional.
MX100: Built-in
The controller is built into the front of the top board.
DGP: DKW10
The DKW10 is a large free-standing “wagon-type” controller. The dimensions are: 50(W) × 31(D) × 59[H) [cm].
The button arrangement is the same as with the MX100. The controller’s rear panel includes MIDI IN and MIDI
OUT jacks.
Control Wagon Front Panel
Control Wagon Rear Panel
