I-11
PRO SERIES: DKC500RW
The DKC500RW includes 8Mbits flash memory for program. The LED is green. In external appearance the
DKC500RW is identical to the DCK500R.
Kemble Made MPX70 YMM Made MX500/22/116: DKC50R
This controller includes 8Mbits flash memory for program and 1MB flash for song memory, the LED is green.
The dimensions of DKC50R are 227(W) × 64(H) × 180(D) [mm].
DKC50R
Control Box Front Panel
PLAY/PAUSE
STOP
REC
SONG SELECT / REV • FWD
PART
L
R
ENTER
REPEAT
FUNC.
METRO-
NOME
BALANCE
TRANSPOSE
TEMPO
VOLUME
•••–10 –8 –6 –4 –2 0
–/NO +/YES
CONTROL UNIT DKC50R
GENERAL
INSTRUMENT
STANDBY
ON
HOST SELECT
TO HOST
MIDI
PC1
PC2
MAC
OUT MIDI IN
TO CONTROL CABLE
FOR PIANO
Control Box Rear Panel
